96 - 256VAC, 50 / 60Hz / 60 Watt

(W) 236 mm x (H) 133 mm x (D) 285 mm, desktop

4.3 kg

UV emission 0 - 100%, white light 0 - 100%, White Balance adjustment

S-Video / composite video, PAL or NTSC available

PAL: 440.000 pixel / (H) 752 x (V) 582
NTSC: 380.000 pixel / (H) 758 / (V) 492

Standard: 130° FOV at 0° DOV

Insertion tube 4 m / 10 mm, camera head 12,7 mm, probe and head stainless steel / polyurethan

Remote Focus control incl. 65° FOV Remote Focus lense system, light control pendant incl. 2,5 m cable

96 - 256VAC, 50 / 60Hz / 60 Watt

(W) 429 mm x (H) 450 mm x (D) 285 mm, reel design

13.1 kg (15 m probe)

UV emission 0 - 100%, white light 0 - 100%, White Balance adjustment

S-Video / composite video, PAL or NTSC available

PAL: 440.000 px / (H) 752 x (V) 582
NTSC: 380.000 px / (H) 758 x (V) 492

Standard: 130° FOV at 0° DOV

Insertion tube 15 m (8 m) / 10 mm, camera head 12.7 mm, probe and head stainless steel / polyurethan

Remote Focus control incl. 65° FOV Remote Focus lense system, light control pendant incl. 2.5 m cable

100 mm distance scope – target / 0° DOV, +/- 20° : 1000 µW/cm² (10 W/m²), remaining visible part less 10 lx. Scope of illumination > FOV

> 10.000 hrs

40 lumen, 2 LED, Scope of illumination > FOV

> 10.000 hrs

Fluorescent magnetic materials, grain size 2-14 µm, fluorescence coefficient min. 2 cd/W, ideal mixing ratio must be evaluated before usage

Typ I (fluorescenting) penetrant according AMS – 2644, Level 3 and 4 / (method A)

All materials emitting visible light due to absortion of 365 nm UV energy

-15°C to +65°C (+5°F to +150°F)

-20°C to +45°C (-4°F to +115°F)

1.5 bar / 15 m water
